Stand-on type for large capacity high lift reach stacker trucks

CQDS series reach stacker cranes are suitable for large capacity and high lift cargo storage applications.
Availability:
Quantity:
  • CQDS

  • KAD

Product Application

CQDS series reach stacker cranes are suitable for large capacity and high lift cargo storage applications. The rated load is 1500Kg-2000kg and the maximum lifting height is 6000mm. It has the feature of moving the gantry forward as a whole, with small turning radius, so that the baffle code at the bottom of the shelves can be ignored. Suitable for large-scale three-dimensional factories, warehouses, supermarkets and wharves to store goods.


1

3

4


Main Features

1. Equipped with electronic drive wheels, which makes the operation more flexible and convenient, and has the function of turning and deceleration.

2.280Ah large-capacity battery can be used for long time work, and the side-pull battery can be replaced at any time.

3.One-piece forged forks with stronger load-bearing and up and down swing function. Suitable for all kinds of single-sided, double-sided, tic-tac-toe and chuan-tac-toe pallets.

4. Large oil cylinder to ensure that the whole gantry move forward gently, up and down smoothly.

Specification


Model

CQDS1030
CQDS1530
CQDS2030
Load Capacity
kg
1000
1500
2000
Lifting Height
mm
3000
3000
3000
Load Center
mm
500
500
500
Fork size
mm
1070*100*40
1070*100*40
1070*100*40
Ground Clearance
mm
45
45
45
Control Way

Steering Wheel
Steering Wheel
Steering Wheel
Speed Regulation Way

Stepless Speed Regulation
Stepless Speed Regulation
Stepless Speed Regulation
Protection Guard Height
mm
2200
2200
2200
Mast Tilt Angle (front/rear)
(°)
3.0/6.0
3.0/6.0
3.0/6.0
The Min.Turning Radius
mm
1600
1600
1800
Driving Speed with Full Loads
km/h
4.4
4.4
4.4
Maximum gradient with full load
°
5
5
5
Battery
V/Ah
24/280
24/280
24/280
Driving Motor
kw
1.2
1.2
1.2
Lifting Motor
kw
4.5
4.5
4.5
Overall dimensions(L*W*H)
mm
2370*1020*2200
2370*1020*2200
2370*1020*2200
Weight
kg
2000
2100
2200
Reference WorkingTime
h
6
6
6
Reach Distance
mm
500
500
500
lncreased height each tonnage
mm
1600/2000/2500/
3000/3500
1600/2000/2500/3000/3500
1600/2000/2500/3000/3500
Max height
mm
2100/1600/1850/
2100/2350
2100/1600/1850/2100/2350
2100/1600/1850/2100/2350
