Hydraulic Manual Paper Roll Lifter Manual Stacker Forklift with clamps

Share to:

Hydraulic Manual Paper Roll Lifter Manual Stacker Forklift with clamps

Manual paper clip stacker uses foot pedal or manual hydraulic stacking, rotating fixture can be rotated 90 degrees, 180 degrees, 360 degrees. It adopts high grade international channel steel frame, more solid and safer. It adopts high quality hydraulic cylinder with imported seals to ensure no oil leakage. Widely used in papermaking, packaging, printing, textile and other industries.

Availability:

Quantity:



Inquire Add to Basket

Model:
MDL025-15
Brand:
KAD

Product Description

Product Description

Hydraulic Manual Paper Roll Lifter Manual Stacker Forklift with clamps

Manual paper clip stacker uses foot pedal or manual hydraulic stacking, rotating fixture can be rotated 90 degrees, 180 degrees, 360 degrees. It adopts high grade international channel steel frame, more solid and safer. It adopts high quality hydraulic cylinder with imported seals to ensure no oil leakage. Widely used in papermaking, packaging, printing, textile and other industries.

Rated load	kg	250
Load center	mm	500
Turning radius	mm	1050
Aisle width	mm	1900
Length	mm	1500
Width	mm	760
Height	mm	2100
Mast		1-stage mast
Adjustable extent of clamp	mm	200~1250
Max height of forks	mm	1500
Min height of forks	mm	200
Rotation angle	°	90°(left and right)
Running speed(load/unload)	km/h	manual
Hoisting speed(load/unload)	mm/s	manual
Descent speed(load/unload)	mm/s	manual
Climbing capability	%	3,5
Braking mode		Wheel brake
Tyres,material		Nylon
Load wheel dimensions	mm	85*80,2pcs
Steering wheel dimensions	mm	180*50,2pcs
Weight	kg	450
