FRB16
KAD
It is used for loading and unloading pallet goods in factory workshop, enterprise warehouse, logistics and distribution center, general cabin, carriage and container.
The biggest feature of the forward electric stacker is that the mast or fork frame can move back and forth, which makes the forward electric stacker more flexible and reduces many troubles when it is used. In addition, the mast of the forward moving electric stacker can move forward along the track inside the leg with the lifting mechanism, which is very convenient for forking goods. In more cases, we will find that the forward electric stacker has the common characteristics of the balanced electric stacker and the electric straddle stacker. In other words, when the mast is raised to the top, the load center of gravity will fall on the outside of the fulcrum, which is equivalent to the electric stacker. The combination of these two performances makes the electric stacker truck have the advantages of flexible operation and high load, which can save space, reduce turning radius, and is more suitable for indoor warehouse operation with narrow channel. In addition, the forward stacker is using forged forks, and the fixed legs are canceled, so it can be used for different pallets.
·Curtis controller, Albright contactor, amp waterproof power connector
·Unique drive shock absorption technology, operating performance is superior
·High frequency MOS integrated control system ensures smooth control of walking and lifting
·The mast is made of forklift special section steel, which is more durable and not easy to deform.
·Pedal standing driving with shock absorber
·Electromagnetic clutch power loss brake, regenerative braking, reverse braking, anti sliding braking on ramp and other multiple braking functions
·Battery under voltage protection function and hydraulic overload protection device fully ensure the forklift working safety.
·When the fork exceeds the maximum height, the automatic power-off function ensures the safety of the operator.
* Reduces employee fatigue, workplace injuries and employee turnover; improves delivery efficiency
* Replaces liftgates, ramps, hoists & conventional pallet jacks
* Unlike forklifts, rides inside with the load, protected from the elements
* Battery powered; charges en route or at your facility
* Can be operated by anyone, expanding your potential delivery workforce
* Can handle any pallet type
| Products | Forward stacker | ||||
| Model | FRB16 | ||||
General | Capacity | kg | 1500 | ||
| Load center | mm | 500 | |||
| Power Type | Battery | ||||
| Operator Type | Ride-on | ||||
Size | Lifting Height | mm | 2500-6000mm | ||
| Cylinder | 2 | ||||
| Fork size | T/W/L | mm | 40/100/1070(forged fork) | ||
| Total Length | mm | 2400 | |||
| Total Width | mm | 1050 | |||
| Total High | mm | 1850 | |||
| Outside of forks | mm | 680(Adjustable) | |||
| Forward volume | mm | 500 | |||
| Turning Radius | mm | 1880 | |||
| Aisle width | mm | 3000 | |||
Performance | Travel speed(Full/Empty Load) | Km/h | 4.5/5.5 | ||
| Grade ability(Empty load) | ％ | 10 | |||
| Weight | kg | 1350 | |||
| Types | Front Load | mm | 250*100,2pcs | ||
| Rear Drive | mm | 250*80,1pc | |||
| Steering wheel | mm | 150*50,2pcs | |||
Drive | Controller | Curtis | |||
| Battery | 24V/210AH | ||||
| Drive motor | KW | 1.5 | |||
| Pump motor | KW | 2.5 | |||
| Charger | V/A | 24V/30A | |||
| Brake | Electric magnet | ||||
| Speed control type | stepless | ||||
