Performance
电子助力转向系统,轻便灵活,具有良好的操控性能,减轻操作者的疲劳。
H型门架更加坚固,稳定。
货叉具有前后倾功能,有利于货物装卸堆垛。
离地间隙更高,爬坡能力更强
转弯时自动减速,功能更加安全可靠
布线整洁,易维护,不易折断
EPS system is light and flexible, has good control performance and reduces operator fatigue.
H-type portal frame is more robust and stable.
Fork has forward and backward tilting function, which is beneficial to load/unload and stack goods.
Higher ground clearance ensures better climbing ability.
Automatic deceleration when turning, more safe and reliable.
Wiring neat, easy to maintain, hard to bend over.
Optional Configuration
侧移器
冷库专用型电池
Side Shifter
Special battery for cold storage
Model | CPD10 CPD15 | ||
Features | Drive system | Battery | |
Driving mode | RIDE-ON | ||
Load Capacity | KG | 1000/1500 | |
Load Center | MM | 500 | |
Weight | Weight(With battery) | KG | 1350/14301510/1590 |
Wheels | Material | PU | |
Size | Lifting Height | MM | 1600/2000/2500/3000 |
Lowest Mast | MM | 2080/1580/1830/2080 | |
Max.Height when operating | MM | 2080/2730/3230/3730 | |
Min.Height of Fork | MM | 80 | |
Length | MM | 2955 | |
Width | MM | 1100 | |
Fork Length | MM | 1070 | |
Wheelbase | MM | 1500 | |
Fork Outside Width | MM | 680 | |
Fork Inside Width | MM | 480 | |
Min.Turning Radius | MM | 1850 | |
Performance data | Driving Speed （Empty/Full Load） | MM/S | 5.0/4.0 |
Lifting Speed （Empty/Full Load） | MM/S | 80/50 | |
Descending Speed （Empty/Full Load） | MM/S | 75/80 | |
Max.Gradient （Empty/Full Load） | ° | 5 | |
Brake | Electromagnetic brake | ||
Driving Motor | KW | DC/1.5 | |
Lifting Motor | KW | DC/2.2 | |
Battery | Capacity | V/Ah | 24/210 |
