Performance
AC drive motor, no carbon brushes ,free maintenance reducing maintenance cost.
Vertical drive motor make the inspection and repair more convenient, which perform much better than the horizontal motor.
The design of integrated micro-switches, easy for replacement.
Battery cover is easy to open, convenient to add distilled water or electrolyte of the battery.
Display with hour time and battery status, to remind the operator to charge battery in time
Controller self-diagnosis system makes troubleshooting easier.
Optional Configuration
Forged Fork
Specially used in Cold storage area
Free-maintenance battery
Model | CDD12 CDD16 CDD20 | ||
Features | Drive system | Battery | |
Driving mode | Standing | ||
Load Capacity | Q(kg) | 1200/1600/2000 | |
Load Center | C(mm) | 500 | |
Weight | Weight(With battery) | kg | 830/880/910/940/970 |
Wheels | Material | PU | |
Size | Lifting Height | H3(mm) | 1600/2000/2500/3000/3500/4000/5000 |
Lowest Mast | H1(mm) | 2080/1580/1830/2080/2330/1820/2020 | |
Max.Height when operating | H4(mm) | 2080/2730/3230/3730/4230/4460/4960 | |
Min.Height of Fork | S(mm) | ≤90 | |
Length | L(mm) | 2130 | |
Width | B(mm) | 850 | |
Fork Length | L2(mm) | 1070 | |
Wheelbase | Y(mm) | 1430 | |
Fork Outside Width | B1(mm) | 550/680 | |
Fork Inside Width | B2(mm) | 225/355 | |
Min.Turning Radius | Wa(mm) | 1738/2099 | |
Performance data | Driving Speed （Empty/Full Load） | Mm/s | 6.5/5.0 |
Lifting Speed （Empty/Full Load） | Mm/s | 80/50 | |
Descending Speed （Empty/Full Load） | Mm/s | 120 | |
Max.Gradient （Empty/Full Load） | % | 6 | |
Brake | Electromagnetic brake | ||
Driving Motor | KW | DC/0.75/1.2/1.5 | |
Lifting Motor | KW | DC/2 | |
Battery | Capacity | V/Ah | 24//210 |
